Genius Handheld X-ray Fluorescence Spectrometer

Genius Handheld XRF Spectrometer features rapid non-destructive elemental identification and composition analysis with SDD Detector for precise detection of any element from Magnesium to Uranium. Performance and accuracy similar to Desktop XRF System combined with convenience and portable size factor of a Handheld XRF. Genius XRF is suitable for wide range of applications with multiple software options to choose from.

Software Options
  • Genius 1000 Precious Metals Analyzer
  • Genius 3000 RoHS Hazardous Substances Analyzer
  • Genius 5000 Alloy & Stainless Steel Analyzer
  • Genius 7000 Mineral Analyzer
  • Genius 9000 Heavy Metals in Soil Software
  • Rapid nondestructive detection and quick measurement with results within five seconds
  • SDD Detector features accuracy similar with most Desktop XRF Systems
  • Built-in GPS records altitude, latitude and longitude during testing
  • Auto X-Ray tube shut off without sample
  • Bluetooth, expandable SD Card for data storage and mini-USB for PC connection
  • Customized workcurves can be added and modified by customer's demand
  • Light elements detection with Helium gas
  • Built-in high definition camera for real-time sample observation
Technical Specifications
Measurable elements: Magnesium(Mg) to Uranium (U)
Limits of Detection 10 ppm
Analysis Range: 10 ppm-99.999%
Test time 5 second results, average test time 20 seconds, testing can be set by user from 5 to 60 seconds
Battery: 780mAh rechargeable lithium battery-up to 8 hours work time
Energy Resolution 139eV
Detector SDD
Sample types Solids, liquids, powders
Light Element testing with optional Helium charging system
Weight: 1.6 kg


Skyray Instruments specializes in the R&D, manufacturing and sales of analytical and measuring instruments in Spectroscopy, Chromatography and Mass Spectroscopy fields. Our Products include X-ray Fluorescence Spectrometry, Atomic Absorption Spectrometry, Gas Chromatography, Inductively Coupled Plasma Spectrometry, Mass Spectrometry and many others. With advanced research and development team Skyray has been providing customers around the world with reliable and affordable Scientific Instruments for more than 20 years
